Swaraj 855 FE vs Kartar 5136
Share
Hide Common Features
Specification
Swaraj 855 FE
Kartar 5136
Engine
- Engine NameRB33TR1Kirloskar 3R 1040, Naturally Aspirated Engine
- HP46-5050
- Displacement3478 cc3120 cc
- Cylinder33
- Rated RPM20002200 RPM
- Cooling SystemWater CooledCopper Radiator with Coolant Cooled System & Overflow Reservoir
- Fuel Tank Capacity62 L55 L
- Air Filter3 Stage wet Air CleanerDry Type Filter with Choke Sensor
Transmission
- Transmission TypeSliding mesh / Partial Constant Mesh (Center Shift/Side Shift)Constant Mesh
- Number of Gears8 F + 2 R / 12 F + 3 R8 Forward + 2 Reverse
- Clutch TypeSingle Clutch/ Dual Clutch /IPTODual Clutch
- Clutch SizeNA280 mm
- Max Forward SpeedNA2.18 - 32.75 kmph
- Max Reverse SpeedNA2.93 - 11.81 kmph
PTO
- PTO HP33.8 kW43.38
- PTO Type4 Multispeed Forward and 1 Reverse SpeedMRPTO, 6 Splines
- PTO Speed540540
Dimensions & Weight
- Length3575 mm3780 mm
- Width1845 mm1820 mm
- Height2295 mmNA
- Wheel Base2250 mm2170 mm
- Weight2220 kg2390 kg
- Ground Clearance437 mm420 mm
- Turning RadiusNAL-8.35M, R-7.4M
Hydraulics & Steering
- Lifting Capacity2000 kg1800 kg
- Hydraulic ControlDCV - OptionalAutomatic Depth & Draft Control
- SteeringPower/MechanicalBalanced Power Steering
- BrakesOil Immersed BrakesOil Immersed Brakes
- 3-Point Linkage3 Point Linkage3 Point Linkage, Cat II
Other Specifications
- Wheel Drive2WD2WD
- Tyre Size6x16/7.50x16 (Front) and 14.9x28/16.9x28 (Rear)7.5x16 (Front) and 14.9x28 Rear
- Price Range768750 - 834375703125-731250
- Warranty6 Years2000 Hours 2 Year
- SeriesFE SeriesNA
