Landforce Disc Harrow Hydraulic-Heavy Technical Specifications
Landforce Disc Harrow Hydraulic-Heavy Features
Brand
Model
Disc Harrow Hydraulic-Heavy
Category
Working Width
210-308 CM
No. of Discs
18 to 28
Type
Power
60-135 HP
No. of Blades
18 - 28
Weight
1440-2240 Kg
Suitable HP
60-135 HP
Gang Bolt
38 Mm Square Rod
Type of Disc
Notched Front Disc And Plain Rear Disc
Tillage Width
2100-3080 mm
Distance Between Discs
228 mm
Bearing Hub
6 to 8
Price
Data Last Updated On: 5 Aug 2026
About Landforce Disc Harrow Hydraulic-Heavy
Landforce Disc Harrow Hydraulic-Heavy Models
| Specification | LFDHHH18 | LFDHHH20 | LFDHHH22 | LFDHHH24 | LFDHHH28 | LFDHHH30 |
|---|---|---|---|---|---|---|
| Working Width | 2100 mm | 2300 mm | 2500 mm | 2780 mm | 3180 mm | 3480 mm |
| Weight | 1830 kg | 1910 kg | 1960 kg | 1990 kg | 2190 kg | 2630 kg |
| gang bolt | 40 mm (Solid Rod) | 40 mm (Solid Rod) | 40 mm (Solid Rod) | 40 mm (Solid Rod) | 40 mm (Solid Rod) | 40 mm (Solid Rod) |
| No. of Disc | 18 | 20 | 22 | 24 | 28 | 30 |
| Type of Disc | Boron Steel, Notched Discs on Front & Plain Discs on Rear | Boron Steel, Notched Discs on Front & Plain Discs on Rear | Boron Steel, Notched Discs on Front & Plain Discs on Rear | Boron Steel, Notched Discs on Front & Plain Discs on Rear | Boron Steel, Notched Discs on Front & Plain Discs on Rear | Boron Steel, Notched Discs on Front & Plain Discs on Rear |
| Distance Between Discs | 228 mm | 228 mm | 228 mm | 228 mm | 228 mm | 228 mm |
| Bearing Hub | 8 | 8 | 8 | 8 | 8 | 10 |
| Tyre Size | 10.00/75-15.3 | 10.00/75-15.3 | 10.00/75-15.3 | 10.00/75-15.3 | 10.00/75-15.4 | 10.00/75-15.5 |
| Tractor HP | 75-90 HP | 75-90 HP | 90-130 HP | 90-130 HP | 140-165 HP | 150-180 HP |
Disc Harrow Hydraulic-Heavy - LFDHHH18
Working Width
2100 mm
Weight
1830 kg
gang bolt
40 mm (Solid Rod)
No. of Disc
18
Type of Disc
Boron Steel, Notched Discs on Front & Plain Discs on Rear
Distance Between Discs
228 mm
Bearing Hub
8
Tyre Size
10.00/75-15.3
Tractor HP
75-90 HP
Disc Harrow Hydraulic-Heavy - LFDHHH20
Working Width
2300 mm
Weight
1910 kg
gang bolt
40 mm (Solid Rod)
No. of Disc
20
Type of Disc
Boron Steel, Notched Discs on Front & Plain Discs on Rear
Distance Between Discs
228 mm
Bearing Hub
8
Tyre Size
10.00/75-15.3
Tractor HP
75-90 HP
Disc Harrow Hydraulic-Heavy - LFDHHH22
Working Width
2500 mm
Weight
1960 kg
gang bolt
40 mm (Solid Rod)
No. of Disc
22
Type of Disc
Boron Steel, Notched Discs on Front & Plain Discs on Rear
Distance Between Discs
228 mm
Bearing Hub
8
Tyre Size
10.00/75-15.3
Tractor HP
90-130 HP
Disc Harrow Hydraulic-Heavy - LFDHHH24
Working Width
2780 mm
Weight
1990 kg
gang bolt
40 mm (Solid Rod)
No. of Disc
24
Type of Disc
Boron Steel, Notched Discs on Front & Plain Discs on Rear
Distance Between Discs
228 mm
Bearing Hub
8
Tyre Size
10.00/75-15.3
Tractor HP
90-130 HP
Disc Harrow Hydraulic-Heavy - LFDHHH28
Working Width
3180 mm
Weight
2190 kg
gang bolt
40 mm (Solid Rod)
No. of Disc
28
Type of Disc
Boron Steel, Notched Discs on Front & Plain Discs on Rear
Distance Between Discs
228 mm
Bearing Hub
8
Tyre Size
10.00/75-15.4
Tractor HP
140-165 HP
Disc Harrow Hydraulic-Heavy - LFDHHH30
Working Width
3480 mm
Weight
2630 kg
gang bolt
40 mm (Solid Rod)
No. of Disc
30
Type of Disc
Boron Steel, Notched Discs on Front & Plain Discs on Rear
Distance Between Discs
228 mm
Bearing Hub
10
Tyre Size
10.00/75-15.5
Tractor HP
150-180 HP
