Fieldking Compact Model Disc Harrow (Auto Angle Adjustment) Technical Specifications
Fieldking Compact Model Disc Harrow (Auto Angle Adjustment) Features
Brand
Model
Compact Model Disc Harrow (Auto Angle Adjustment)
Category
No. of Discs
18-20
Tractor Power (HP)
60-80 HP
Type
Power
60-80 HP
No. of Blades
18 - 20
Weight
960-1200 kg
Suitable HP
60-80 HP
Gang Bolt
32 mm ( Solid Sq. Rod)
Type of Disc
Notched Disc In Front Gang & Plain Disc In Rear Gang
Disc Diameter
610 x 4.5T-660 x 6T mm
Tillage Width
2128-2345 mm
Distance Between Discs
228 mm
Bearing Hub
8
Price
Data Last Updated On: 5 Aug 2026
About Fieldking Compact Model Disc Harrow (Auto Angle Adjustment)
Fieldking Compact Model Disc Harrow (Auto Angle Adjustment) Models
| Specification | FKCMDHAAA-24-18 | FKCMDHAAA-26-18 | FKCMDHAAA-24-20 | FKCMDHAAA-26-20 |
|---|---|---|---|---|
| Weight | 960 kg | 1070 kg | 1095 kg | 1200 kg |
| gang bolt | 32 / 1.3" (Solid Sq. Rod) | 32 / 1.3" (Solid Sq. Rod) | 32 / 1.3" (Solid Sq. Rod) | 32 / 1.3" (Solid Sq. Rod) |
| No. of Disc | 18 | 18 | 20 | 20 |
| Type of Disc | Notched Disc in Front Gang & Plain Disc in Rear Gang | Notched Disc in Front Gang & Plain Disc in Rear Gang | Notched Disc in Front Gang & Plain Disc in Rear Gang | Notched Disc in Front Gang & Plain Disc in Rear Gang |
| Disc Diameter | 610-660 mm | 610-660 mm | 610-660 mm | 610-660 mm |
| Tillage Width | 2128 mm | 2128 mm | 2345 mm | 2345 mm |
| Distance Between Discs | 228 mm | 228 mm | 228 mm | 228 mm |
| Bearing Hub | 8 | 8 | 8 | 8 |
| Tractor HP | 60-70 HP | 60-70 HP | 70-80 HP | 70-80 HP |
Compact Model Disc Harrow (Auto Angle Adjustment) - FKCMDHAAA-24-18
Weight
960 kg
gang bolt
32 / 1.3" (Solid Sq. Rod)
No. of Disc
18
Type of Disc
Notched Disc in Front Gang & Plain Disc in Rear Gang
Disc Diameter
610-660 mm
Tillage Width
2128 mm
Distance Between Discs
228 mm
Bearing Hub
8
Tractor HP
60-70 HP
Compact Model Disc Harrow (Auto Angle Adjustment) - FKCMDHAAA-26-18
Weight
1070 kg
gang bolt
32 / 1.3" (Solid Sq. Rod)
No. of Disc
18
Type of Disc
Notched Disc in Front Gang & Plain Disc in Rear Gang
Disc Diameter
610-660 mm
Tillage Width
2128 mm
Distance Between Discs
228 mm
Bearing Hub
8
Tractor HP
60-70 HP
Compact Model Disc Harrow (Auto Angle Adjustment) - FKCMDHAAA-24-20
Weight
1095 kg
gang bolt
32 / 1.3" (Solid Sq. Rod)
No. of Disc
20
Type of Disc
Notched Disc in Front Gang & Plain Disc in Rear Gang
Disc Diameter
610-660 mm
Tillage Width
2345 mm
Distance Between Discs
228 mm
Bearing Hub
8
Tractor HP
70-80 HP
Compact Model Disc Harrow (Auto Angle Adjustment) - FKCMDHAAA-26-20
Weight
1200 kg
gang bolt
32 / 1.3" (Solid Sq. Rod)
No. of Disc
20
Type of Disc
Notched Disc in Front Gang & Plain Disc in Rear Gang
Disc Diameter
610-660 mm
Tillage Width
2345 mm
Distance Between Discs
228 mm
Bearing Hub
8
Tractor HP
70-80 HP
