Fieldking Extra Heavy Duty Hydraulic Harrow Technical Specifications
Fieldking Extra Heavy Duty Hydraulic Harrow Features
Brand
Model
Extra Heavy Duty Hydraulic Harrow
Category
No. of Discs
24-36
Tractor Power (HP)
125-210 HP
Type
Power
125-235 HP
No. of Blades
24 - 36
Weight
2674-3150 kg
Suitable HP
125-235 HP
Gang Bolt
40 mm (Solid Sq. Rod)
Type of Disc
Notched Disc In Front Gang & Plain Disc In Rear Gang
Disc Diameter
660 x 6T-710 x 7T mm
Tillage Width
2700-3900 mm
Distance Between Discs
228 mm
Bearing Hub
8 -12
Tyre Size
13.0/55-16 (14 PR), 400/60-15.5 (18 PR)
Weight With Dead Weight
3174-3650 Kg
Price
Data Last Updated On: 8 Aug 2026
About Fieldking Extra Heavy Duty Hydraulic Harrow
Fieldking Extra Heavy Duty Hydraulic Harrow Models
| Specification | FKEHDHH-26-24 | FKEHDHH-26-28 | FKEHDHH-26-32 | FKEHDHH-26-36 |
|---|---|---|---|---|
| Weight | 2674 kg | 2806 kg | 2958 kg | 3150 kg |
| gang bolt | 40 / 1.6" (Solid Sq. Rod) | 40 / 1.6" (Solid Sq. Rod) | 40 / 1.6" (Solid Sq. Rod) | 40 / 1.6" (Solid Sq. Rod) |
| No. of Disc | 24 | 28 | 32 | 36 |
| Type of Disc | Notched Disc in Front Gang & Plain Disc in Rear Gang | Notched Disc in Front Gang & Plain Disc in Rear Gang | Notched Disc in Front Gang & Plain Disc in Rear Gang | Notched Disc in Front Gang & Plain Disc in Rear Gang |
| Disc Diameter | 660-710 mm | 660-710 mm | 660-710 mm | 660-710 mm |
| Distance Between Discs | 228 mm | 228 mm | 228 mm | 228 mm |
| Bearing Hub | 8 | 8 | 8 | 12 |
| Width of Cut | 2700 mm | 3100 mm | 3500 mm | 3900 mm |
| Tyre Size | 13.0/55-16 (14 PR), 400/60-15.5 (18 PR) | 13.0/55-16 (14 PR), 400/60-15.5 (18 PR) | 13.0/55-16 (14 PR), 400/60-15.5 (18 PR) | 13.0/55-16 (14 PR), 400/60-15.5 (18 PR) |
| weight with dead weight | 3174 kg | 3306 kg | 3458 kg | 3650 kg |
| Tractor HP | 125-140 HP | 145-165 HP | 170-200 HP | 210-235 HP |
Extra Heavy Duty Hydraulic Harrow - FKEHDHH-26-24
Weight
2674 kg
gang bolt
40 / 1.6" (Solid Sq. Rod)
No. of Disc
24
Type of Disc
Notched Disc in Front Gang & Plain Disc in Rear Gang
Disc Diameter
660-710 mm
Distance Between Discs
228 mm
Bearing Hub
8
Width of Cut
2700 mm
Tyre Size
13.0/55-16 (14 PR), 400/60-15.5 (18 PR)
weight with dead weight
3174 kg
Tractor HP
125-140 HP
Extra Heavy Duty Hydraulic Harrow - FKEHDHH-26-28
Weight
2806 kg
gang bolt
40 / 1.6" (Solid Sq. Rod)
No. of Disc
28
Type of Disc
Notched Disc in Front Gang & Plain Disc in Rear Gang
Disc Diameter
660-710 mm
Distance Between Discs
228 mm
Bearing Hub
8
Width of Cut
3100 mm
Tyre Size
13.0/55-16 (14 PR), 400/60-15.5 (18 PR)
weight with dead weight
3306 kg
Tractor HP
145-165 HP
Extra Heavy Duty Hydraulic Harrow - FKEHDHH-26-32
Weight
2958 kg
gang bolt
40 / 1.6" (Solid Sq. Rod)
No. of Disc
32
Type of Disc
Notched Disc in Front Gang & Plain Disc in Rear Gang
Disc Diameter
660-710 mm
Distance Between Discs
228 mm
Bearing Hub
8
Width of Cut
3500 mm
Tyre Size
13.0/55-16 (14 PR), 400/60-15.5 (18 PR)
weight with dead weight
3458 kg
Tractor HP
170-200 HP
Extra Heavy Duty Hydraulic Harrow - FKEHDHH-26-36
Weight
3150 kg
gang bolt
40 / 1.6" (Solid Sq. Rod)
No. of Disc
36
Type of Disc
Notched Disc in Front Gang & Plain Disc in Rear Gang
Disc Diameter
660-710 mm
Distance Between Discs
228 mm
Bearing Hub
12
Width of Cut
3900 mm
Tyre Size
13.0/55-16 (14 PR), 400/60-15.5 (18 PR)
weight with dead weight
3650 kg
Tractor HP
210-235 HP
