Fieldking Trailed Offset Disc Harrow (With Tyre) Technical Specifications
Fieldking Trailed Offset Disc Harrow (With Tyre) Features
Brand
Model
Trailed Offset Disc Harrow (With Tyre)
Category
Working Width
150-213 CM
No. of Discs
12 to 18
Type
No. of Blades
12 - 18
Weight
590-690 Kg
Suitable HP
30-75 HP
Gang Bolt
'C' Class Heavy Duty ERW Tube
Type of Disc
Plain Disc
Disc Diameter
610 x 4.5T mm
Tillage Width
1449-2130 mm
Distance Between Discs
228 mm
Bearing Hub
4
Price
Data Last Updated On: 2 Aug 2026
About Fieldking Trailed Offset Disc Harrow (With Tyre)
Fieldking Trailed Offset Disc Harrow (With Tyre) Models
| Specification | FKTODHT-12 | FKTODHT-14 | FKTODHT-16 | FKTODHT-18 |
|---|---|---|---|---|
| Weight | 590 kg | 660 kg | 725 kg | 790 kg |
| gang bolt | ‘C’ Class Heavy Duty ERW Tube | ‘C’ Class Heavy Duty ERW Tube | ‘C’ Class Heavy Duty ERW Tube | ‘C’ Class Heavy Duty ERW Tube |
| No. of Disc | 12 | 14 | 16 | 18 |
| Type of Disc | Plain Disc | Plain Disc | Plain Disc | Plain Disc |
| Disc Diameter | 610 mm | 610 mm | 610 mm | 610 mm |
| Tillage Width | 1449 mm | 1635 mm | 1882 mm | 2130 mm |
| Distance Between Discs | 228 mm | 228 mm | 228 mm | 228 mm |
| Bearing Hub | 4 | 4 | 4 | 4 |
| Tractor HP | 30-40 HP | 45-55 HP | 60-70 HP | 65-75 HP |
Trailed Offset Disc Harrow (With Tyre) - FKTODHT-12
Weight
590 kg
gang bolt
‘C’ Class Heavy Duty ERW Tube
No. of Disc
12
Type of Disc
Plain Disc
Disc Diameter
610 mm
Tillage Width
1449 mm
Distance Between Discs
228 mm
Bearing Hub
4
Tractor HP
30-40 HP
Trailed Offset Disc Harrow (With Tyre) - FKTODHT-14
Weight
660 kg
gang bolt
‘C’ Class Heavy Duty ERW Tube
No. of Disc
14
Type of Disc
Plain Disc
Disc Diameter
610 mm
Tillage Width
1635 mm
Distance Between Discs
228 mm
Bearing Hub
4
Tractor HP
45-55 HP
Trailed Offset Disc Harrow (With Tyre) - FKTODHT-16
Weight
725 kg
gang bolt
‘C’ Class Heavy Duty ERW Tube
No. of Disc
16
Type of Disc
Plain Disc
Disc Diameter
610 mm
Tillage Width
1882 mm
Distance Between Discs
228 mm
Bearing Hub
4
Tractor HP
60-70 HP
Trailed Offset Disc Harrow (With Tyre) - FKTODHT-18
Weight
790 kg
gang bolt
‘C’ Class Heavy Duty ERW Tube
No. of Disc
18
Type of Disc
Plain Disc
Disc Diameter
610 mm
Tillage Width
2130 mm
Distance Between Discs
228 mm
Bearing Hub
4
Tractor HP
65-75 HP
