Soil Master Heavy Duty Disc Harrow Technical Specifications
Soil Master Heavy Duty Disc Harrow Features
Data Last Updated On: 6 Aug 2026
About Soil Master Heavy Duty Disc Harrow
Soil Master Heavy Duty Disc Harrow Models
| Specification | SMHDD-18 | SMHDD-20 | SMHDD-22 | SMHDD-24 | SMHDD-26 | SMHDD-28 | SMHDD-30 | SMHDD-32 | SMHDD-34 | SMHDD-36 | SMHDD-38 | SMHDD-40 | SMHDD-44 | SMHDD-48 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Working Width | 198 cm | 180 / 220 cm | 198 / 242 cm | 216 / 264 cm | 234 / 286 cm | 252 / 308 cm | 270 / 330 cm | 288 / 352 cm | 306 / 374 cm | 324 cm | 342 cm | 360 cm | 396 cm | 432 cm |
| Weight | 980/1150 kg | 480 / 520 / 1100 / 1150 kg | 525 / 565 / 1200 / 1250 kg | 570 / 615 / 1300 / 1400 kg | 620 / 675 / 1400 / 1500 kg | 670 / 725 / 1550 / 1600 kg | 715 / 780 / 1650 / 1750 kg | 760 / 830 / 1750 / 1850 kg | 810 / 880 / 1850 / 1950 kg | 860/935 kg | 905/985 kg | 950/1140 kg | 1150/1140 kg | 1145/1245 kg |
| Disc Diameter | 56/61 cm | 46/51/56/61 cm | 46/51/56/61 cm | 46/51/56/61 cm | 46/51/56/61 cm | 46/51/56/61 cm | 46/51/56/61 cm | 46/51/56/61 cm | 46/51/56/61 cm | 46/51/56/61 cm | 46/51/56/61 cm | 46/51/56/61 cm | 46/51/56/61 cm | 46/51/56/61 cm |
| Distance Between Discs | 220 mm | 180/220 mm | 180/220 mm | 180/220 mm | 180/220 mm | 180/220 mm | 180/220 mm | 180/220 mm | 180/220 mm | 180/220 mm | 180/220 mm | 180/220 mm | 180/220 mm | 180/220 mm |
| Tractor HP | 65-70 HP | 45–50 / 70–75 HP | 50–55 / 75–80 HP | 55–60 / 80–90 HP | 60–65 / 90–120 HP | 65–70 / 120–140 HP | 70–75 / 140–160 HP | 75–80 / 160–170 HP | 80–85 / 170–200 HP | 85-90 HP | 90-95 HP | 95-100 HP | 100-105 HP | 105-110 HP |
Heavy Duty Disc Harrow - SMHDD-18
Working Width
198 cm
Weight
980/1150 kg
Disc Diameter
56/61 cm
Distance Between Discs
220 mm
Tractor HP
65-70 HP
Heavy Duty Disc Harrow - SMHDD-20
Working Width
180 / 220 cm
Weight
480 / 520 / 1100 / 1150 kg
Disc Diameter
46/51/56/61 cm
Distance Between Discs
180/220 mm
Tractor HP
45–50 / 70–75 HP
Heavy Duty Disc Harrow - SMHDD-22
Working Width
198 / 242 cm
Weight
525 / 565 / 1200 / 1250 kg
Disc Diameter
46/51/56/61 cm
Distance Between Discs
180/220 mm
Tractor HP
50–55 / 75–80 HP
Heavy Duty Disc Harrow - SMHDD-24
Working Width
216 / 264 cm
Weight
570 / 615 / 1300 / 1400 kg
Disc Diameter
46/51/56/61 cm
Distance Between Discs
180/220 mm
Tractor HP
55–60 / 80–90 HP
Heavy Duty Disc Harrow - SMHDD-26
Working Width
234 / 286 cm
Weight
620 / 675 / 1400 / 1500 kg
Disc Diameter
46/51/56/61 cm
Distance Between Discs
180/220 mm
Tractor HP
60–65 / 90–120 HP
Heavy Duty Disc Harrow - SMHDD-28
Working Width
252 / 308 cm
Weight
670 / 725 / 1550 / 1600 kg
Disc Diameter
46/51/56/61 cm
Distance Between Discs
180/220 mm
Tractor HP
65–70 / 120–140 HP
Heavy Duty Disc Harrow - SMHDD-30
Working Width
270 / 330 cm
Weight
715 / 780 / 1650 / 1750 kg
Disc Diameter
46/51/56/61 cm
Distance Between Discs
180/220 mm
Tractor HP
70–75 / 140–160 HP
Heavy Duty Disc Harrow - SMHDD-32
Working Width
288 / 352 cm
Weight
760 / 830 / 1750 / 1850 kg
Disc Diameter
46/51/56/61 cm
Distance Between Discs
180/220 mm
Tractor HP
75–80 / 160–170 HP
Heavy Duty Disc Harrow - SMHDD-34
Working Width
306 / 374 cm
Weight
810 / 880 / 1850 / 1950 kg
Disc Diameter
46/51/56/61 cm
Distance Between Discs
180/220 mm
Tractor HP
80–85 / 170–200 HP
Heavy Duty Disc Harrow - SMHDD-36
Working Width
324 cm
Weight
860/935 kg
Disc Diameter
46/51/56/61 cm
Distance Between Discs
180/220 mm
Tractor HP
85-90 HP
Heavy Duty Disc Harrow - SMHDD-38
Working Width
342 cm
Weight
905/985 kg
Disc Diameter
46/51/56/61 cm
Distance Between Discs
180/220 mm
Tractor HP
90-95 HP
Heavy Duty Disc Harrow - SMHDD-40
Working Width
360 cm
Weight
950/1140 kg
Disc Diameter
46/51/56/61 cm
Distance Between Discs
180/220 mm
Tractor HP
95-100 HP
Heavy Duty Disc Harrow - SMHDD-44
Working Width
396 cm
Weight
1150/1140 kg
Disc Diameter
46/51/56/61 cm
Distance Between Discs
180/220 mm
Tractor HP
100-105 HP
Heavy Duty Disc Harrow - SMHDD-48
Working Width
432 cm
Weight
1145/1245 kg
Disc Diameter
46/51/56/61 cm
Distance Between Discs
180/220 mm
Tractor HP
105-110 HP
