Fieldking Hunter Harrow Technical Specifications
Fieldking Hunter Harrow Features
Brand
Model
Hunter Harrow
Category
No. of Discs
18-26
Tractor Power (HP)
60-110 HP
Type
Weight
645-1874 kg
Suitable HP
60-110 HP
Gang Bolt
32 (Solid Square Road)
Type of Disc
Notched Disc In front Gang and Plain Disc in Rear Gang
Disc Diameter
560x 4T mm
Distance Between Discs
225 mm
Bearing Hub
8
Price
Data Last Updated On: 31 Jul 2026
About Fieldking Hunter Harrow
Fieldking Hunter Harrow Models
| Specification | FKMODHHS-18 | FKMODHHS-20 | FKMODHHS-22 | FKMODHHS-24 | FKMODHHS-26 |
|---|---|---|---|---|---|
| Weight | 645 kg | 685 kg | 770 kg | 810 kg | 850 kg |
| gang bolt | 32 / (Solid Sq. Rod) | 32 / (Solid Sq. Rod) | 32 / (Solid Sq. Rod) | 32 / (Solid Sq. Rod) | 32 / (Solid Sq. Rod) |
| No. of Disc | 18 | 20 | 22 | 24 | 26 |
| Type of Disc | Notched Disc in Front Gang & Plain Disc in Rear Gang | Notched Disc in Front Gang & Plain Disc in Rear Gang | Notched Disc in Front Gang & Plain Disc in Rear Gang | Notched Disc in Front Gang & Plain Disc in Rear Gang | Notched Disc in Front Gang & Plain Disc in Rear Gang |
| Disc Diameter | 560 mm | 560 mm | 560 mm | 560 mm | 560 mm |
| Distance Between Discs | 225 mm | 225 mm | 225 mm | 225 mm | 225 mm |
| Bearing Hub | 8 | 8 | 8 | 8 | 8 |
| Width of Cut | 2034 mm | 2259 mm | 2484 mm | 2709 mm | 2934 mm |
| Tractor HP | 60-70 HP | 70-80 HP | 80-90 HP | 90-100 HP | 100-110 HP |
Hunter Harrow - FKMODHHS-18
Weight
645 kg
gang bolt
32 / (Solid Sq. Rod)
No. of Disc
18
Type of Disc
Notched Disc in Front Gang & Plain Disc in Rear Gang
Disc Diameter
560 mm
Distance Between Discs
225 mm
Bearing Hub
8
Width of Cut
2034 mm
Tractor HP
60-70 HP
Hunter Harrow - FKMODHHS-20
Weight
685 kg
gang bolt
32 / (Solid Sq. Rod)
No. of Disc
20
Type of Disc
Notched Disc in Front Gang & Plain Disc in Rear Gang
Disc Diameter
560 mm
Distance Between Discs
225 mm
Bearing Hub
8
Width of Cut
2259 mm
Tractor HP
70-80 HP
Hunter Harrow - FKMODHHS-22
Weight
770 kg
gang bolt
32 / (Solid Sq. Rod)
No. of Disc
22
Type of Disc
Notched Disc in Front Gang & Plain Disc in Rear Gang
Disc Diameter
560 mm
Distance Between Discs
225 mm
Bearing Hub
8
Width of Cut
2484 mm
Tractor HP
80-90 HP
Hunter Harrow - FKMODHHS-24
Weight
810 kg
gang bolt
32 / (Solid Sq. Rod)
No. of Disc
24
Type of Disc
Notched Disc in Front Gang & Plain Disc in Rear Gang
Disc Diameter
560 mm
Distance Between Discs
225 mm
Bearing Hub
8
Width of Cut
2709 mm
Tractor HP
90-100 HP
Hunter Harrow - FKMODHHS-26
Weight
850 kg
gang bolt
32 / (Solid Sq. Rod)
No. of Disc
26
Type of Disc
Notched Disc in Front Gang & Plain Disc in Rear Gang
Disc Diameter
560 mm
Distance Between Discs
225 mm
Bearing Hub
8
Width of Cut
2934 mm
Tractor HP
100-110 HP
