Fieldking Compact Model Disc Harrow Technical Specifications
Fieldking Compact Model Disc Harrow Features
Brand
Model
Compact Model Disc Harrow
Category
Working Width
191-277 CM
No. of Discs
16 to 24
Type
No. of Blades
16 - 24
Weight
840-1170 Kg
Suitable HP
50-125 HP
Gang Bolt
28-40 mm ( Solid Sq. Rod)
Type of Disc
Notched Disc In Front Gang & Plain Disc In Rear Gang
Disc Diameter
610 x 4.5T-660 x 6T mm
Tillage Width
1912-2778 mm
Distance Between Discs
228 mm
Bearing Hub
6 to 8
Price
Data Last Updated On: 1 Aug 2026
About Fieldking Compact Model Disc Harrow
Fieldking Compact Model Disc Harrow Models
| Specification | FKCMDH -26-16 | FKCMDH -26-18 | FKCMDH -26-20 | FKCMDH -26-22 | FKCMDH -26-24 |
|---|---|---|---|---|---|
| Weight | 840 kg | 960 kg | 1025 kg | 1095 kg | 1170 kg |
| gang bolt | 28 / 1.1"/40 / 1.6" (Solid Sq. Rod) | 28 / 1.1"/40 / 1.6" (Solid Sq. Rod) | 28 / 1.1"/40 / 1.6" (Solid Sq. Rod) | 28 / 1.1"/40 / 1.6" (Solid Sq. Rod) | 28 / 1.1"/40 / 1.6" (Solid Sq. Rod) |
| No. of Disc | 16 | 18 | 20 | 22 | 24 |
| Type of Disc | Notched Disc in Front Gang & Plain Disc in Rear Gang | Notched Disc in Front Gang & Plain Disc in Rear Gang | Notched Disc in Front Gang & Plain Disc in Rear Gang | Notched Disc in Front Gang & Plain Disc in Rear Gang | Notched Disc in Front Gang & Plain Disc in Rear Gang |
| Disc Diameter | 610-660 mm | 610-660 mm | 610-660 mm | 610-660 mm | 610-660 mm |
| Tillage Width | 1912 mm | 2128 mm | 2345 mm | 2562 mm | 2778 mm |
| Distance Between Discs | 228 mm | 228 mm | 228 mm | 228 mm | 228 mm |
| Bearing Hub | 6 | 8 | 8 | 8 | 8 |
| Tractor HP | 50-60 HP | 60-70 HP | 70-80 HP | 90-100 HP | 105-125 HP |
Compact Model Disc Harrow - FKCMDH -26-16
Weight
840 kg
gang bolt
28 / 1.1"/40 / 1.6" (Solid Sq. Rod)
No. of Disc
16
Type of Disc
Notched Disc in Front Gang & Plain Disc in Rear Gang
Disc Diameter
610-660 mm
Tillage Width
1912 mm
Distance Between Discs
228 mm
Bearing Hub
6
Tractor HP
50-60 HP
Compact Model Disc Harrow - FKCMDH -26-18
Weight
960 kg
gang bolt
28 / 1.1"/40 / 1.6" (Solid Sq. Rod)
No. of Disc
18
Type of Disc
Notched Disc in Front Gang & Plain Disc in Rear Gang
Disc Diameter
610-660 mm
Tillage Width
2128 mm
Distance Between Discs
228 mm
Bearing Hub
8
Tractor HP
60-70 HP
Compact Model Disc Harrow - FKCMDH -26-20
Weight
1025 kg
gang bolt
28 / 1.1"/40 / 1.6" (Solid Sq. Rod)
No. of Disc
20
Type of Disc
Notched Disc in Front Gang & Plain Disc in Rear Gang
Disc Diameter
610-660 mm
Tillage Width
2345 mm
Distance Between Discs
228 mm
Bearing Hub
8
Tractor HP
70-80 HP
Compact Model Disc Harrow - FKCMDH -26-22
Weight
1095 kg
gang bolt
28 / 1.1"/40 / 1.6" (Solid Sq. Rod)
No. of Disc
22
Type of Disc
Notched Disc in Front Gang & Plain Disc in Rear Gang
Disc Diameter
610-660 mm
Tillage Width
2562 mm
Distance Between Discs
228 mm
Bearing Hub
8
Tractor HP
90-100 HP
Compact Model Disc Harrow - FKCMDH -26-24
Weight
1170 kg
gang bolt
28 / 1.1"/40 / 1.6" (Solid Sq. Rod)
No. of Disc
24
Type of Disc
Notched Disc in Front Gang & Plain Disc in Rear Gang
Disc Diameter
610-660 mm
Tillage Width
2778 mm
Distance Between Discs
228 mm
Bearing Hub
8
Tractor HP
105-125 HP
